MD electic hoist
MD electic hoist

MD1 Electric hoist

MD1 Electric Wrie Rope Hoist is a small-sized lifting equipment, which is installed on the single girder, bridge cranes, gantry cranes, jib cranes for material handling. As one of the commonly used material handling equipment, the MD1 Electric Hoist is usually used in factory, mining, railway, port, and storage, etc.

The MD1 Electric Hoist has two speed options which coordinate with each other to realize the efficient material handling work with precision. The lifting capacity of MD1 Electric Hoist is 0.5 – 32 ton and the working class is M3 and M4. The main parameter of MD1 Electric Hoist is as follow:

  • Electric Hoist Product Type:  MD1 wire rope hoist
  • MD1 Electric Hoist Lifting Capacity: 0.5~32t
  • MD1 Electric Hoist Lifting Height:  6~50m
  • MD1 Electric Hoist Working Class: M3,M4
  • MD1 Electric Hoist Ambient Temperature:     -25~40℃

Advantages of MD1 Electric Hoist

MD1 Electric Hoist of DQCRANES has the following advantages:

  • The MD1 Electric Hoist is designed with compact structure, with the features of small size, light weight, standardized parts, etc.
  • The MD1 Electric Hoist has fast and slow lifting speed, which can make the lifting stable and easy.
  • The MD1 Electric Hoist has big lifting capacity, high working efficiency, and long working life.
  • The MD1 Electric Hoist is easy to operation and convenient to repair.

Features of MD1 Electric Hoist

The MD1 Electric Hoist from DQCRANES has the following features:

  1. On lifting motor.

The lifting motor of MD1 Electric Hoist is a bigger moment motor of taper rotor, with asynchronous braking, thus the extra braking is needed. The motor loading lasting rate is 25%, ensuring high safety.

The lifting motor of double speed hoist has the B or F grade insulation and the safety class of IP44/ P154.

  1. On Lifting Speed Reducer

The lifting speed reducer of double speed hoist adopts Class 3 dead axle bevel wheel, with a long working life. The gear is made of heated alloy steel with high intension.

Tank body and tank cover of the reducer are made of best cast iron, strictly assembled and sealed well. The reducer is a separate device, which is convenient to be installed and uninstalled.

The lifting speed reducer has a very high efficiency and high reliability during moving.

  1. Protect Function

Safety is always the concern of DQCRANES. Our hoisting equipment is equipped with various devices to ensure the safety of hoist and operators. The MD1 Electric Hoist is matched with brennschluss stopper, to ensure the safety of hoist during moving. The hoist also installed with head punch protection device.

  1. Wire rope.

The wire rope used is confirming with the national standards GB/T 20118-2006(6*37+1), which has good resistance to wear.

  1. Operation device

The MD1 Electric Hoist has two operation devices: the wire rope operating and remote control. It is very light and handy.

MD1 electric hoist is a MD1 Electric Hoist for high precision material handling. CE MD electric hoist with good price for sale from Chinese electric hoist manufacturer, Dongqi Hoist and Crane. Check the MD1 electric hoist. More on electric hoist services.
