Low-headroom wire rope hoist
Low headroom wire rope hoist overview
Basic information of low headroom wire rope hoist is as follow:
- Application: Construction Usage, Workshop Usage, Mineral Area Usage
- Main Girder Form: Double or Single Girder
- Certification: ISO9001: 2000, CE
- Capacity: From 1.6ton to 12.5ton
- Electric Components: Schneider Brand
- Quality Level: High Quantity
- Origin: China
- Type: Single Girder Crane
- Sling Type: Wire Rope
- Power Source: Electric
- Condition: New
- Lifting Height: From 6m to 24m
- Wire Rope: Italy Wire Rope
- Warranty: 1 Year
- Specification: 1.6T to 12.5T
Advantages of low headroom wire rope hoist
Compare with CD/MD wire rope hoist, the low headroom wire rope hoist is newly designed with modern technology, which has the following advantage:
- Gearbox of the low headroom wire rope hoist is made of aluminum and no oil leak out
- Low-noise gearing design
- Double speed design is available to the low headroom wire rope hoist.
- The low headroom wire rope hoist is designed with life-time lubrication
- More safe brake system
- Unique limit switch
Features of low headroom wire rope hoist:
- The normal travelling speed: 20m/min (dual speed 20/6 is optional)
- Hoist electrics cubicle including low voltage transformer
- Motor protection IP54 insulation class F
- Push button box with emergency button
- Rope guide for use in aggressive environment
- Remote control is optional, Hook with safety latch
- Hoist is made under the FEM European standard, with planetary gearbox(low noises and free maintenance).
- The motor and gearbox are installed at the same side, help the hosit to run smoothly and increase of service life.
