Top running overhead crane
Usually, a top-running overhead crane system is much heavier than under hung crane equipment. For top-running crane systems, the end trucks are supported on crane rails, which are attached to the top of the crane runway.
Types of top running overhead crane
Top running overhead crane is generally grouped in single girder, double girder, box girder top running overhead cranes, which are selected according to your application conditions. Top running overhead bridge cranes are designed to travel on top of a runway system that is either supported by engineered columns or building columns. Double girder designs typically provide you a better hook height than single girder designs as the hoist is mounted on top of the bridge rather than underneath. Contact us for your custom top running overhead crane now.
Single Girder Top Running Overhead Cranes
Single girder top running overhead crane has the features:
- Providing you excellent value for your custom application,
- Single girder designs make the top running overhead crane be cost effective without compromising performance.
- Over the lifetime of the top running overhead crane, you will save on new support structures as it has reduced wheel loads, which enables your This allows you to add more lifting capabilities to your runway structurewithout upgrading.
Double Girder Top Running Overhead Crane
Double girder top running overhead crane has the following features:
- Double girder is designed for applications with load capacities typically over 25 tons for heavy material handling.
- Double girder top running cranes are used when you need a complete lifting solution.
- Top running Double girder cranes give a better height of lift compared to a single girder crane as the hook travels between the beams.
Top running crane of Dongqi Hoist and Crane
Double girder top running crane with hook
Double girder top running crane with hook parameters
Lifting Capacity: 15-100t
Span Length: 10.5~31.5m
Lifting Height: 6~18m
Working Class: A4
LH type double girder hoist top running trolley crane
LH type hoist trolley top running crane crane parameters
Lifting Capacity: 15
Span Length: 10.5~31.5m
Lifting Height: 6~18m
Working Class: A4
QB type explosion proof top running crane
QB type explosion proof top running crane parameters
Lifting Capacity: 5~75t
Span Length: 10.5~31.5m
Lifting Height: 6~18m
Working Class: A4
Explosion-proof Grade：ExdⅡBT4、ExdⅡCT4
QD type double girder top running crane with hook
QD type double girder top running crane with hook parameters
Lifting capacity :5-320t
Span Length: 10.5~31.5m
Lifting Height: 6~18m
Working Class: A5, A6
Ambient Temperature: -20~40℃
QDY type foundry top running crane
QDY type foundry top running crane crane parameters
Lifting Capacity: 5~30t
Span Length: 10.5~31.5m
Lifting Height: 6~35m
Crane Dive:IP54 or IP44,level F insulation
Working Class: A5 A6
Top running crane with carrier-beamTop running crane crane with carrier-beam parameters
Lifting Capacity: 1~350t
Span Length: 6~45m
Lifting Height: 3~60m
Lifting Speed: 7.8-15.5m/min
Crane Speed: 20-30m/min
Working Class: A3-A7
